FANUC A06B-0213-B400#0100 | αiS 2/5000 HV AC Servo Motor

FANUC A06B-0213-B400#0100 | αiS 2/5000 HV AC Servo Motor

Overview:

The FANUC A06B-0213-B400#0100 is an αiS 2/5000 HV model AC servo motor from FANUC's αi series, known for its high precision, reliability, and efficiency. This motor is widely used in CNC machinery, robotics, and automated material handling systems, offering stable torque and high-speed operation for industrial automation applications.

Key Features:

• High-Precision Motion Control – Ensures accurate positioning in CNC and automation systems.
• Compact & Robust Design – Optimized for space-saving installations and long-term durability.
• High-Speed Performance – Operates at a rated speed of 5000 min⁻¹.
• Reliable & Energy-Efficient – Supports continuous industrial operation with optimized power consumption.
• Seamless Integration – Compatible with FANUC CNC controllers and automation platforms.

Technical Specifications:

• Model: A06B-0213-B400#0100
• Stall Torque: 2.0 Nm
• Rated Output Power: 1.0 kW (1.3 HP)
• Rated Speed: 5000 min⁻¹
• Maximum Speed: 5000 min⁻¹
• Rotor Inertia: 0.000515 kg·m²
• Cooling Method: High Voltage (HV)

Ambient Conditions:

• Operating Temperature: 0 to 55°C
• Storage Temperature: -25 to 70°C
• Humidity: 10% to 95% (non-condensing)
• Vibration Resistance: Built for industrial environments

Applications:

• CNC Machinery – Ensures precise movement in milling, turning, and grinding applications.
• Robotics – Enhances motion control in robotic arms and automated systems.
• Material Handling & Automation – Optimized for conveyor systems and assembly lines.
• High-Speed Industrial Applications – Provides stable and dynamic motion performance.

Why Choose the FANUC A06B-0213-B400#0100?

The FANUC A06B-0213-B400#0100 is a top-tier AC servo motor, offering high-speed, precision control, and energy efficiency. Its compact yet powerful design, industrial-grade reliability, and seamless integration with FANUC systems make it an excellent choice for automation and CNC applications.

Order Now

Fast shipping and worldwide delivery available.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
