Weintek mTV-100 | HDMI HMI Interface for Industrial Automation

Overview

The Weintek mTV-100 is a compact HMI interface that connects to external HDMI displays, transforming them into full-featured operator interfaces. With support for 720p resolution, Ethernet, and serial communication, it's ideal for applications requiring larger or remote displays without the bulk of traditional HMIs.

Key Features

• HDMI Output – Supports 1280x720 resolution for clear visuals on external displays

• Compact Design – Slim profile suitable for DIN-rail mounting

• Fan-less Cooling – Silent operation with reduced maintenance

• Communication Ports – Includes Ethernet, RS-232, and RS-485 interfaces

• USB Host Port – Connect peripherals like USB drives or touch inputs

• SD Card Slot – Expand storage for projects and data logging

• Built-in RTC – Real-time clock for time-stamped data

• Power Isolation – Enhanced protection for industrial environments

Technical Specifications

• Processor: 32-bit RISC Cortex-A8 600MHz

• Memory: 256 MB Flash, 256 MB RAM

• Ethernet: 10/100/1000 Base-T x 1

• Serial Ports: COM1: RS-232, COM2: RS-485 2W/4W, COM3: RS-485 2W

• USB Host: USB 2.0 x 1

• SD Card Slot: Supports SD/SDHC

• HDMI Output Resolution: 1280 x 720

• Audio Output: HDMI Audio Output

• Power Input: 24±20%VDC

• Power Consumption: 230mA@24VDC

• Dimensions (WxHxD): 130 x 115 x 27 mm

• Mounting: 35mm DIN rail mounting

• Operating Temperature: -20°C to +55°C

• Storage Temperature: -20°C to +70°C

• Relative Humidity: 10% to 90% (non-condensing)

• Certifications: CE, cULus Listed

Applications

• Industrial Automation – Enhance control systems with large or remote displays

• OEM Solutions – Integrate into custom machinery requiring flexible HMI options

• Process Monitoring – Display real-time data on large screens in control rooms

• Cost-Effective HMI Expansion – Upgrade existing systems without replacing entire HMIs

Why Choose the mTV-100?

• Scalable Display Options – Use any HDMI-compatible screen to suit your needs

• Space-Saving Design – Ideal for installations with limited panel space

• Versatile Connectivity – Multiple communication ports for broad compatibility

• Reliable Performance – Built for industrial environments with robust features

Order Now

Available for immediate shipping.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
