Turck BI2-M12-AP6X-H1141

Turck BI2-M12-AP6X-H1141

Overview

The Turck BI2-M12-AP6X-H1141 is a compact inductive proximity sensor designed for precise metal detection in tight installation spaces. With a 2 mm sensing distance and PNP output, it is ideal for high-precision applications like assembly, robotics, or small automated equipment.

Key Features

• 2 mm sensing distance — high precision detection

• PNP Normally Open (NO) output for direct PLC integration

• M12 × 1 threaded housing — standard mechanical format

• LED indicator for visible status and switching feedback

• Durable construction for industrial environments

• Designed for minimal space footprint

Technical Specifications

• Model: BI2-M12-AP6X-H1141

• Technology: Inductive proximity (metal sensing)

• Thread Size: M12 × 1

• Sensing Distance: 2 mm (nominal)

• Output Type: PNP, Normally Open (NO)

• Operating Voltage: 10–30 V DC

• Protection Rating: IP67-type industrial sealing

• Operating Temperature: –25 °C to +70 °C

• Max Load Current: Approx. 200 mA typical

• Housing Material: Metal barrel format

Applications

• Detecting small metal parts in humanoid robots or small automation

• Position sensing in tight fixture locations

• Assembly machines and tooling where space is constrained

• Machines with continuous motion and minimal installation clearance

• Industries with oil, vibration, and dust exposure

Why Choose Turck BI2-M12-AP6X-H1141?

• Extremely compact size for flexible installation

• High accuracy in short-distance metal detection

• Stable performance in harsh industrial conditions

• Trusted product from Turck for long-term reliability

Order Now

Integrate precise and compact detection into your automation system with the Turck BI2-M12-AP6X-H1141 — the small-footprint inductive sensor for exact positioning tasks.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
