Siemens 6ED1052-1MD08-0BA0

Siemens 6ED1052-1MD08-0BA0 | LOGO! AM2 Analog Input Module – 2x 0–10V AI, 12/24V DC, IP20

Overview

The Siemens 6ED1052-1MD08-0BA0 is a LOGO! AM2 analog input expansion module designed for use with LOGO! 8 logic controllers. It provides 2 analog voltage inputs (0–10V) to monitor continuous values such as temperature, pressure, and level sensors in compact automation environments.

Key Features

• Analog Inputs: 2 channels

• Input Range: 0–10V DC

• Resolution: 10-bit

• Supply Voltage: 12/24V DC

• Mounting: DIN rail next to LOGO! base module

• Protection Rating: IP20

• Status Indication: LED indicators per channel

Technical Specifications

• Part Number: 6ED1052-1MD08-0BA0

• Series: LOGO! 8

• Input Impedance: >100 kΩ

• Update Time: ≤500 ms

• Operating Temperature: 0°C to +55°C

• Dimensions (W x H x D): Approx. 35.5 x 90 x 60 mm

• Weight: Approx. 120 g

• Certifications: CE, UL, RoHS compliant

Applications

• Analog sensor monitoring

• Building automation (temperature, humidity, lighting)

• Tank level and pressure control

• Compact machines requiring analog data input

• Educational and training labs

Why Choose the 6ED1052-1MD08-0BA0?

• Compact Expansion: Adds 2 analog inputs to LOGO! 8 systems

• Easy Installation: DIN rail mounting with direct module connection

• Wide Voltage Support: Operates on both 12V and 24V DC

• Versatile Monitoring: Supports any 0–10V analog sensor

• Siemens Reliability: Built for continuous use in industrial and building systems

Order Now

The Siemens 6ED1052-1MD08-0BA0 LOGO! AM2 analog module is available and ready for worldwide delivery.
