Overview

The Siemens 6AV2124-0QC02-0AX2 is a robust 7” Human Machine Interface (HMI) from the SIMATIC KTP Basic line. Featuring a bright TFT touch display and PROFINET interface, it is ideal for simple visualization and operation in small to mid-sized automation systems. With six tactile function keys, it offers flexible input options in a compact design.

Key Features

• 7” widescreen TFT touch display (800 × 480 pixels)

• 6 configurable function keys

• 65536 colors with LED backlighting

• PROFINET/Ethernet communication interface

• Configurable via WinCC Basic in TIA Portal

• Compact design for easy panel integration

• USB interface for data transfer and updates

• Fanless operation for long-term reliability

Technical Specifications

• Siemens Code: 6AV2124-0QC02-0AX2

• Series: SIMATIC HMI Basic

• Display Size: 7” widescreen (16:9)

• Resolution: 800 × 480 pixels

• Color Depth: 65k colors

• Touchscreen: Resistive

• Function Keys: 6

• Interface: 1× PROFINET (Ethernet), 1× USB

• Rated Voltage: 24 V DC

• Power Consumption: ~4.8 W

• Protection Rating: IP65 (front), IP20 (rear)

• Operating Temperature: 0 °C to +50 °C

• Software Compatibility: TIA Portal, WinCC Basic V13 or later

Applications

• Small-scale machinery and equipment

• Operator control in packaging and material handling

• OEM machine panels

• Cost-efficient HMI for basic automation

• Panel integration in industrial systems

Why Choose Siemens 6AV2124-0QC02-0AX2?

• Clear 7” touch display with easy usability

• Reliable control via tactile function keys

• Seamless integration with Siemens TIA Portal

• PROFINET communication for fast connectivity

• Robust and compact design for industrial use

Order Now

Enhance your system’s user interface with the Siemens 6AV2124-0QC02-0AX2 — a cost-effective and reliable HMI for basic industrial control tasks.
