Schneider Electric LMC201CAA10000 – PacDrive 3 Motion Controller

Overview

The Schneider Electric LMC201CAA10000 is an advanced PacDrive 3 motion controller built to handle applications requiring up to 8 motion axes. Equipped with 8 digital inputs, 8 digital outputs, and 4 touch probe inputs with configurable anti-bounce filtering, it ensures precise and reliable control in automation environments.

Operating on a 24 V DC supply with 30 W power consumption, the controller offers robust performance with 512 MB DDR2 RAM and 128 kB NVRAM. It supports all IEC 61131-3 programming languages for maximum flexibility and integrates seamlessly into industrial systems via Ethernet, CANopen, RS232/RS485, and USB.

Key Features

• Brand: Schneider Electric

• Range: PacDrive 3

• Model: LMC201CAA10000

• Motion Axes: 8

• Rated Supply Voltage: 24 V DC

• Power Consumption: 30 W

• Memory: 512 MB DDR2 RAM, 128 kB NVRAM

• Programming Languages: LD, ST, FBD, SFC, CFC, IL

• I/O:

  • 8 digital inputs (IEC 61131-2 Type 1)

  • 4 touch probe inputs (configurable 100 µs…4.29 s)

  • 8 digital outputs, 500 mA each

• Interfaces:

  • 2 × Ethernet RJ45 (Sercos)

  • 1 × Ethernet 10/100BASE-T RJ45 (FTP/HTTP)

  • 1 × Ethernet RJ45 master encoder

  • 1 × RS232/RS485 RJ45 serial link

  • 1 × CAN SUB-D 9 (CANopen)

  • 1 × USB type A

Technical Specifications

• Dimensions (W × H × D): 44 × 270 × 222 mm (1.7 × 10.6 × 8.7 in)

• Net Weight: 2.2 kg (4.9 lb)

• Degree of Protection: IP20 (EN/IEC 60529)

• Operating Temperature: +5…55 °C (41…131 °F)

• Relative Humidity: 5…95 % non-condensing

• Altitude: 0…2000 m (0…6562 ft)

• Vibration Resistance: 3.5 mm (5–8.4 Hz), 10 m/s² (8.4–150 Hz)

• Shock Resistance: 150 m/s² for 6 ms

• Standards: EN/IEC 61131-2, UL 508, CSA C22.2

• Certifications: CE, CSA, EAC, cULus

Applications

• High-performance packaging and robotics systems

• Multi-axis synchronization in industrial automation

• Advanced motion and logic control integration

• Networked control via Ethernet and CANopen

• Assembly and processing machines

Why Choose Schneider Electric LMC201CAA10000

• Controls up to 8 motion axes with precision

• Compact yet powerful with rich I/O capability

• IEC 61131-3 language support for programming flexibility

• Wide range of integrated communication interfaces

• Built to Siemens global standards for safety and reliability

Order Now

The Schneider Electric LMC201CAA10000 PacDrive 3 motion controller is available and ships worldwide.

Return to PacDrive LMC Controllers

Explore the full range of Schneider Electric PacDrive | Motion Control & Automation Solutions
