Pepperl+Fuchs NJ5-30GK-S1N

Pepperl+Fuchs NJ5-30GK-S1N | Inductive Sensor, 5 mm, 2-Wire DC, IP67

Overview:

The Pepperl+Fuchs NJ5-30GK-S1N (Part No. 250947) is a rectangular inductive proximity sensor with a 5 mm flush sensing distance and a 2-wire DC output. Designed in a compact GK-style plastic housing, it offers easy installation and reliable detection of metallic objects in demanding industrial environments.

Key Features:

• Sensing Distance: 5 mm (flush)

• Output Type: 2-wire DC, Normally Open (NO)

• Operating Voltage: 5–60 VDC

• Housing Style: Rectangular GK body

• Connection: Cable (typically 2 m PVC cable)

• Protection Rating: IP67

• Switching Frequency: Up to 1,000 Hz

• Mounting Type: Through-hole or surface mount

• Material: Plastic housing, suitable for tight spaces

Technical Specifications:

• Model Number: NJ5-30GK-S1N

• Part Number: 250947

• Sensing Method: Inductive proximity

• Installation Type: Flush

• Voltage Drop: ≤ 6 V

• Load Current: 2–100 mA

• Leakage Current: ≤ 1.8 mA

• Short-Circuit Protection: Yes

• Polarity Reversal Protection: Yes

• Operating Temperature: -25°C to +70°C

• Cable Length: Typically 2 m, 2-wire PVC

• Weight: Approx. 60 g

Applications:

• Industrial Machinery: Detect metal parts in automation systems

• Packaging Equipment: Confirm presence of components

• Conveyor Lines: Monitor items in motion

• OEM Assemblies: Embedded in tight mechanical layouts

• Robotics: Reliable sensing for proximity control

Why Choose the NJ5-30GK-S1N?

✅ Compact GK-style housing fits where cylindrical sensors can't
✅ 5 mm flush sensing with consistent switching performance
✅ 2-wire system simplifies wiring in control circuits
✅ IP67 rating protects against water and dust ingress
✅ Reliable for continuous-duty industrial applications

Order Now:

Available and ships worldwide.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
