Overview

The Omron NS15-TX01B-V2 is a 15-inch touchscreen Human-Machine Interface (HMI) designed to provide operators with an intuitive and efficient interface for monitoring and controlling industrial automation systems. Featuring a high-resolution 1024x768 XGA TFT display capable of displaying 256 colors, this HMI ensures clear and detailed visualization of processes. With built-in Ethernet, RS-232C, and RS-422 communication ports, it offers versatile connectivity options to integrate seamlessly into various control systems.

Key Features

• Display: 15-inch XGA TFT touchscreen with 1024x768 resolution and 256-color display.

• Memory: 60MB of screen data capacity for comprehensive application development.

• Communication Ports:

  • Ethernet: 10/100 Base-T for network connectivity.

  • RS-232C: For serial communication with controllers and other devices.

  • RS-422: Provides additional serial communication options.

• Touchscreen Interface: Analog resistive touch panel for intuitive user interaction.

• Compact Design: Despite its large display, the unit maintains a sleek profile suitable for various industrial environments.

• Versatile Mounting: Designed for panel mounting, facilitating easy integration into control panels.

Technical Specifications

• Model Number: NS15-TX01B-V2

• Display Size: 15 inches

• Display Type: TFT color LCD

• Resolution: 1024 x 768 pixels (XGA)

• Display Colors: 256 colors

• Touch Panel Type: Analog resistive

• Screen Data Capacity: 60MB

• Communication Interfaces:

  • Ethernet: 10/100 Base-T

  • RS-232C: 1 port

  • RS-422: 1 port

• Power Supply Voltage: 24 VDC

• Power Consumption: 45 W max.

• Operating Temperature: 0°C to 50°C

• Storage Temperature: -20°C to 60°C

• Operating Humidity: 35% to 85% (0 to 40°C), 35% to 60% (40 to 50°C) (with no condensation)

• Mounting Method: Panel mount

• Dimensions: [Dimensions not specified in the provided sources]

• Weight: Approximately 4.2 kg

• Certifications: CE, cULus, NK, Lloyd

Applications

• Industrial Automation: Provides operators with real-time data visualization and control capabilities for manufacturing processes.

• Process Monitoring: Enables monitoring and control of complex processes in industries such as chemical, pharmaceutical, and food processing.

• Machine Control: Facilitates user interaction with machinery, allowing for parameter adjustments and status monitoring.

• Building Management Systems: Serves as an interface for monitoring and controlling building utilities and systems.

Why Choose Omron NS15-TX01B-V2?

• High-Resolution Display: The 15-inch XGA TFT screen offers clear and detailed visuals, enhancing operator efficiency.

• Robust Connectivity: Multiple communication ports, including Ethernet, RS-232C, and RS-422, provide flexible integration options.

• Ample Memory: 60MB of screen data capacity allows for the development of complex and comprehensive HMI applications.

• User-Friendly Interface: The analog resistive touchscreen ensures intuitive operation, even with gloved hands.

• Reliable Performance: Designed to operate in industrial environments with a wide temperature range and compliance with international standards.

Order Now

Available for immediate shipping worldwide. Contact us to bundle with Omron PLCs, I/O modules, and other automation components to complete your system integration.
