Omron CP1L-EL20DT1-D

Omron CP1L-EL20DT1-D | High-Performance Compact PLC for Industrial Automation

Overview

The Omron CP1L-EL20DT1-D is a compact and versatile Programmable Logic Controller (PLC) designed for a wide range of industrial automation applications. Featuring 12 digital inputs, 8 PNP transistor outputs, and a built-in Ethernet port, this PLC offers robust performance and seamless integration into various control systems. Its 24V DC power supply and support for high-speed counters and pulse outputs make it suitable for precise control tasks.

Key Features

• Inputs: 12 digital inputs compatible with 24V DC signals, including support for high-speed counting.

• Outputs: 8 PNP (sourcing) transistor outputs capable of handling solid-state switching, suitable for fast and reliable operations.

• Built-in Ethernet Port: Facilitates easy network connectivity and remote monitoring, enhancing communication capabilities.

• High-Speed Counters: Supports multiple high-speed counters, enabling precise measurement and control of rapid processes.

• Pulse Outputs: Provides pulse output functionality for controlling servo or stepper motors, allowing for accurate motion control.

• Expandable: Supports expansion with additional modules to increase I/O capacity, accommodating growing system requirements.

• Compact Design: Space-saving form factor suitable for installations with limited space, without compromising on performance.

• Programming Software: Compatible with Omron's CX-One software suite, offering a user-friendly environment for programming and configuration.

Technical Specifications

• Model Number: CP1L-EL20DT1-D

• Power Supply: 24V DC

• Inputs: 12 digital inputs (24V DC)

• Outputs: 8 PNP transistor outputs (sourcing)

• Communication Ports: 1 Ethernet port, 1 USB port

• High-Speed Counters: Supports up to 100 kHz

• Pulse Outputs: Up to 100 kHz for 2 axes

• Memory Capacity: Program capacity of 5K steps

• Operating Temperature Range: 0°C to 55°C

• Mounting: DIN rail mounting

• Dimensions: Compact design for easy integration into control panels

• Certifications: CE, cULus

Applications

• Material Handling: Controls conveyors, sorters, and automated storage systems with precision.

• Packaging Machines: Manages operations of packaging equipment, ensuring synchronization and efficiency.

• Food and Beverage Industry: Automates processes such as filling, labeling, and packaging, adhering to industry standards.

• Textile Machinery: Oversees operations of textile manufacturing equipment, enhancing productivity and quality.

• Building Automation: Controls HVAC systems, lighting, and access control for energy-efficient building management.

Why Choose Omron CP1L-EL20DT1-D?

• Integrated Ethernet Connectivity: Simplifies network integration and remote access, reducing setup time and costs.

• High-Speed Processing: Capable of handling rapid input and output operations, essential for high-speed automation tasks.

• Scalable Solution: Expandable I/O options allow for customization and future system growth without significant redesign.

• User-Friendly Programming: Compatible with Omron's CX-One software, providing an intuitive platform for programming and system configuration.

• Reliable Performance: Built to withstand industrial environments, ensuring consistent operation and minimal downtime.

Order Now

Available for immediate shipping worldwide. Contact us to bundle with Omron expansion modules, programming cables, and other automation components to complete your system setup.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
