Infineon FS820R08A6P2LB

Infineon FS820R08A6P2LB

Overview

The Infineon FS820R08A6P2LB is a high-performance single IGBT module rated at 820 A and 800 V, housed in the robust PrimePACK™ 2 package. It is designed for demanding industrial applications requiring high efficiency, low switching losses, and excellent thermal management. Ideal for power inverters, motor drives, and energy systems.

Key Features

• Collector-Emitter Voltage: 800 V

• Continuous Collector Current: 820 A

• Trench/Field-stop IGBT technology

• Low VCE(sat) and switching losses

• Integrated fast recovery diode

• PrimePACK 2 package for compact design

• High thermal cycling capability

• Chassis mount with high isolation

Technical Specifications

• Part Number: FS820R08A6P2LB

• Configuration: Single IGBT

• Voltage Rating: 800 V

• Current Rating: 820 A

• Package: PrimePACK 2

• Isolation Voltage: ≥2500 V

• Mounting: Chassis mount

• Operating Temperature: –40 °C to +150 °C (Tj)

• NTC Thermistor: Included

• Switching Frequency: Up to 8 kHz

Applications

• High-power industrial inverters

• Renewable energy systems

• Electric motor drives

• Railway and traction systems

• High-efficiency power conversion

Why Choose the FS820R08A6P2LB

• Reliable high-current performance

• Optimized thermal and electrical characteristics

• Ideal for compact and high-power designs

• Backed by Infineon’s trusted IGBT technology

Order Now

The Infineon FS820R08A6P2LB IGBT module is available and ships worldwide.

Return to the Infineon IGBT Modules collection for more models, ratings, and configurations.

Explore the Power Electronics Components main category to discover diodes, thyristors, GTOs, MOSFETs, and other semiconductor solutions

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
