GE IC695PBM300

GE Fanuc IC695PBM300 | RX3i PROFIBUS Master Module | DP Communications | High-Speed Fieldbus Interface

Overview

The GE Fanuc IC695PBM300 is a PROFIBUS DP Master module designed for the PACSystems RX3i platform. It enables RX3i controllers to function as a PROFIBUS DP master, allowing communication and control of up to 125 slave devices over a single high-speed PROFIBUS network. Ideal for connecting field devices such as drives, sensors, and remote I/O in industrial automation systems.

Key Features

• Function: PROFIBUS DP Master for RX3i

• Device Capacity: Controls up to 125 PROFIBUS slaves

• Baud Rate: 9.6 Kbps to 12 Mbps (auto-detected)

• Diagnostics: On-module LEDs and GSD file support

• Configuration: Via GE Machine Edition software

• Hot-Swappable: Yes (with proper system support)

Technical Specifications

• Model Number: IC695PBM300

• Protocol: PROFIBUS DP-V0 Master

• Network Speed: Up to 12 Mbps

• Max Devices: 125 slaves

• Connector: 9-pin D-sub female (standard PROFIBUS interface)

• Power Requirements: 5V @ 500 mA

• Operating Temperature: 0°C to 60°C

• Certifications: UL, CE, RoHS

Applications

• Distributed fieldbus control in manufacturing and process plants

• Communication with PROFIBUS-compatible drives, sensors, and I/O modules

• OEM machinery with PROFIBUS integration

• Automation systems requiring high-speed deterministic communication

Why Choose the IC695PBM300?

• Seamless PROFIBUS Integration: Enables RX3i to control extensive field networks

• High Device Capacity: Communicates with up to 125 slave devices

• Flexible Speed Options: Auto-detects baud rate for easier setup

• Robust Performance: Built for industrial environments and high-speed control

Order Now

The GE Fanuc IC695PBM300 PROFIBUS DP master module is available and ready for worldwide shipping.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
