GE IC695ALG626

GE Fanuc IC695ALG626 | RX3i Analog Output Module | 6 Channels | Voltage/Current | High-Resolution DAC

Overview

The GE Fanuc IC695ALG626 is a 6-channel analog output module designed for the PACSystems RX3i series. Each output can be individually configured for either voltage or current, making it highly adaptable for various industrial control applications. With high-resolution digital-to-analog conversion (15-bit) and strong reliability, it's ideal for precision control of actuators, drives, and other analog devices.

Key Features

• Output Types: Voltage (0–10V, ±10V) or Current (0–20mA, 4–20mA)

• Channels: 6 independently configurable outputs

• Resolution: 15-bit DAC for accurate signal output

• Group Isolation: Isolated from backplane and logic

• Diagnostics: Built-in fault and open-wire detection

• Hot-Swappable: Yes (within supported RX3i systems)

Technical Specifications

• Model Number: IC695ALG626

• Output Ranges:

  • Voltage: 0–10V, ±10V

  • Current: 0–20mA, 4–20mA

• Resolution: 15-bit

• Accuracy: ±0.1% of full scale

• Load Requirements:

  • Voltage ≥ 1 kΩ

  • Current ≤ 750 Ω

• Power Requirements: 5V @ 150 mA, 24V @ 200 mA

• Operating Temperature: 0°C to 60°C

• Certifications: UL, CE, RoHS

Applications

• Analog control of drives, valves, actuators, and instrumentation

• SCADA and DCS systems requiring analog output

• Process automation requiring precise signal generation

• OEM machine control solutions with mixed output requirements

Why Choose the IC695ALG626?

• Flexible Output Configuration: Voltage or current per channel

• High Resolution and Accuracy: Ideal for fine-tuned analog control

• Diagnostic Capabilities: Fault detection for enhanced reliability

• Industrial-Grade Design: Engineered for tough environments

Order Now

The GE Fanuc IC695ALG626 analog output module is available and ready for fast global shipping.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
