GE IC695ALG616

GE Fanuc IC695ALG616 | RX3i Analog Output Module | 8 Channels | Voltage/Current Output | High-Resolution DAC

Overview

The GE Fanuc IC695ALG616 is an 8-channel analog output module designed for the PACSystems RX3i platform. It provides both voltage and current outputs, software-configurable per channel. With high-resolution digital-to-analog conversion (15-bit), the IC695ALG616 is ideal for precise analog signal generation in industrial automation and process control.

Key Features

• Output Types: Voltage (±10V, 0–10V) or Current (0–20mA, 4–20mA)

• Channels: 8 independently configurable outputs

• Resolution: 15-bit digital-to-analog conversion

• Channel Isolation: Group isolated from logic and field

• Diagnostics: Channel fault detection and status LEDs

• Hot-Swappable: Yes (in RX3i systems with proper precautions)

Technical Specifications

• Model Number: IC695ALG616

• Output Ranges:

  • Voltage: 0–10V, ±10V

  • Current: 0–20mA, 4–20mA

• Resolution: 15 bits (0.003% of full scale)

• Accuracy: ±0.1% of full scale

• Output Update Rate: <1 ms per channel

• Isolation: 250V between field and logic

• Power Requirements: 5V @ 160 mA, 24V @ 250 mA

• Operating Temperature: 0°C to 60°C

• Certifications: UL, CE, RoHS compliant

Applications

• Process control systems requiring analog output

• Variable speed drive control

• Valve positioning and actuator control

• OEM machinery with analog control demands

• High-resolution analog interfacing for SCADA and DCS systems

Why Choose the IC695ALG616?

• Flexible Output Options: Each channel supports current or voltage

• High Accuracy & Resolution: Precision analog control for industrial applications

• Scalable Design: Ideal for both small and large control systems

• Built-In Diagnostics: Simplifies maintenance and commissioning

Order Now

The GE Fanuc IC695ALG616 analog output module is available and ready to ship worldwide.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
