GE IC695ALG608

GE Fanuc IC695ALG608 | RX3i Analog Output Module | 8 Channels | 0–20mA / 4–20mA | High-Density Current Output

Overview

The GE Fanuc IC695ALG608 is an 8-channel analog output module for the PACSystems RX3i series, providing high-density current loop outputs of 0–20mA or 4–20mA. With high accuracy, configurable ranges, and channel-to-channel isolation, it is ideal for industrial process control and analog actuator applications.

Key Features

• Output Type: Analog current (0–20mA or 4–20mA)

• Channels: 8 individually isolated outputs

• Resolution: 16-bit D/A conversion

• Configurable Ranges: Per channel via software

• Isolation: Channel-to-channel and from logic

• Diagnostics: Overrange, open-wire detection, and module status

• Hot-Swappable: Yes (when used in supported RX3i systems)

Technical Specifications

• Model Number: IC695ALG608

• Output Ranges:

  • 0–20mA

  • 4–20mA

• Resolution: 16 bits

• Load Resistance: 0–750 Ohms

• Accuracy: ±0.1% of full scale

• Update Rate: <2 ms per channel

• Power Requirements: 5V @ 120 mA, 24V @ 190 mA

• Operating Temperature: 0°C to 60°C

• Certifications: UL, CE, RoHS

Applications

• Analog control of valves, actuators, and drives

• Process automation requiring precise current output

• OEM machinery with multi-channel analog requirements

• High-density current loop control in industrial systems

Why Choose the IC695ALG608?

• High-Channel Density: 8 outputs in a single-slot module

• Flexible Output Ranges: Software-configurable for each channel

• Superior Accuracy: 16-bit resolution for smooth control

• Full Isolation: Between channels and system logic for safety

Order Now

The GE Fanuc IC695ALG608 is in stock and available for immediate global shipping.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
