GE IC695ALG508

GE Fanuc IC695ALG508 | RX3i Analog Output Module | 8 Channels | Voltage/Current | High-Resolution DAC | Group-Isolated

Overview

The GE Fanuc IC695ALG508 is an 8-channel analog output module designed for the PACSystems RX3i platform. Each channel is configurable for voltage or current output, offering flexibility for a variety of industrial analog control applications. With 15-bit resolution and group isolation, the IC695ALG508 delivers precise and reliable signal control for actuators, drives, and process instruments.

Key Features

• Output Types: Voltage (±10V, 0–10V) or Current (0–20mA, 4–20mA)

• Channels: 8 individually configurable analog outputs

• Resolution: 15-bit DAC for high precision

• Isolation: Group-isolated from backplane and logic

• Diagnostics: Built-in open-wire detection and fault monitoring

• Hot-Swappable: Yes (in supported RX3i configurations)

Technical Specifications

• Model Number: IC695ALG508

• Output Ranges:

  • Voltage: 0–10V, ±10V

  • Current: 0–20mA, 4–20mA

• Resolution: 15-bit

• Accuracy: ±0.1% of full scale

• Minimum Load:

  • Voltage: ≥ 1 kΩ

  • Current: ≤ 750 Ω

• Power Requirements: 5V @ 150 mA, 24V @ 250 mA

• Operating Temperature: 0°C to 60°C

• Certifications: UL, CE, RoHS compliant

Applications

• Analog control of process equipment and instrumentation

• Output to variable speed drives, control valves, and signal converters

• OEM systems requiring multi-format analog output

• Industrial control systems with precision signal output needs

Why Choose the IC695ALG508?

• High-Resolution Output: Ideal for fine control in analog applications

• Versatile Signal Configuration: Supports both current and voltage formats

• Group Isolation: Enhances signal integrity and system safety

• Integrated Diagnostics: Reduces maintenance and setup time

Order Now

The GE Fanuc IC695ALG508 analog output module is in stock and ready for fast worldwide shipping.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
