GE IC695ALG112

GE Fanuc IC695ALG112 | RX3i Analog Input Module | 16 Channels | Voltage/Current | High-Density Monitoring

Overview

The GE Fanuc IC695ALG112 is a 16-channel analog input module for the PACSystems RX3i platform. It supports both voltage and current inputs, configurable on a per-channel basis, and is ideal for high-density signal monitoring applications. The module offers high-resolution data acquisition and is designed for reliable performance in industrial control environments.

Key Features

• Input Types: Voltage (0–10V, ±10V) and Current (0–20mA, 4–20mA)

• Channels: 16 configurable analog input channels

• Resolution: 15-bit

• Group-Isolated: Inputs are isolated from logic but not channel-to-channel

• Diagnostics: Open wire and range error detection

• Hot-Swappable: Yes (with supported RX3i configurations)

Technical Specifications

• Model Number: IC695ALG112

• Input Ranges:

  • Voltage: 0–10V, ±10V

  • Current: 0–20mA, 4–20mA

• Resolution: 15-bit

• Accuracy: ±0.1% of full scale

• Impedance: >10 MΩ (voltage), 250 Ω (current)

• Power Requirements: 5V @ 120 mA, 24V @ 200 mA

• Isolation: Group-isolated from backplane and logic

• Operating Temperature: 0°C to 60°C

• Certifications: UL, CE, RoHS

Applications

• High-density analog signal acquisition

• Monitoring sensors, transducers, and process instruments

• OEM machine systems requiring scalable analog input

• SCADA and industrial automation systems

Why Choose the IC695ALG112?

• High Channel Density: 16 inputs in one module for space savings

• Flexible Signal Support: Handles voltage and current per channel

• Reliable Measurement: High-resolution and accuracy for critical systems

• Efficient Diagnostics: Built-in fault detection simplifies maintenance

Order Now

The GE Fanuc IC695ALG112 analog input module is in stock and ready for fast international shipping.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
