GE IC694PWR330

GE Fanuc IC694PWR330 | RX3i Power Supply Module | 24VDC Input | 30W Output | Compact Universal Backplane Mount

Overview

The GE Fanuc IC694PWR330 is a 24VDC input power supply module designed for use with the PACSystems RX3i series. Delivering 30 watts of total output power, it supplies regulated 5VDC and 3.3VDC to backplane-connected RX3i modules such as CPUs, I/Os, and communications cards. Compact and efficient, it installs directly into the universal RX3i baseplate.

Key Features

• Input Voltage: 24VDC nominal (range: 18–30 VDC)

• Output Power: 30W total

• Backplane Outputs:

  • +5VDC @ 4A

  • +3.3VDC @ 0.5A

• Mounting: Installs in RX3i universal backplane

• Status Indicators: Power OK LED

• Protection: Internal fuse, overvoltage, and overcurrent protection

• Hot-Swappable: No

Technical Specifications

• Model Number: IC694PWR330

• Input Voltage Range: 18–30 VDC

• Input Current: 1.4A typical at 24VDC

• Output Power: 30 watts

• Efficiency: >70%

• Power Consumption: Approx. 34W

• Isolation: Between input and backplane outputs

• Operating Temperature: 0°C to 60°C

• Certifications: UL, CE

Applications

• Powering RX3i CPUs and I/O modules in DC-powered systems

• OEM control panels using 24VDC field power

• Industrial automation systems with centralized or distributed architectures

• Compact PLC racks in transportation, energy, and infrastructure applications

Why Choose the IC694PWR330?

• DC Input Flexibility: Perfect for battery-backed and 24VDC field systems

• Compact and Efficient: Saves rack space and power

• Reliable Operation: Designed for harsh industrial environments

• Easy Integration: Snap-in RX3i backplane installation

Order Now

The GE Fanuc IC694PWR330 is available for fast global delivery.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
