GE IC694MDL753

GE Fanuc IC694MDL753 | RX3i Discrete Input Module | 32 Points | 125VDC | Positive Logic | Group-Isolated

Overview

The GE Fanuc IC694MDL753 is a 32-point 125VDC discrete input module designed for the PACSystems RX3i series. It supports positive logic inputs (sinking field devices) and is organized into two isolated groups of 16 channels each. This module is ideal for high-voltage DC signal acquisition in industrial automation systems, utilities, and OEM equipment.

Key Features

• Input Type: 125VDC, positive logic (sinking input devices)

• Channels: 32 inputs, 2 groups of 16

• Group Isolation: Isolated from each other and logic

• Status LEDs: 32 green indicators (1 per channel)

• Hot-Swappable: Yes (in supported RX3i configurations)

Technical Specifications

• Model Number: IC694MDL753

• Nominal Input Voltage: 125VDC

• Input Voltage Range: 0–150VDC

• On-State Voltage: 85–150VDC

• Off-State Voltage: 0–30VDC

• On-State Current (typ): 2.3 mA

• Off-State Current (max): 1.1 mA

• Input Delay: Typical 7 ms ON/OFF

• Power Requirements: 5V @ 80 mA

• Isolation Voltage: 250V between field groups and logic

• Operating Temperature: 0°C to 60°C

• Certifications: UL, CE

Applications

• High-voltage DC input monitoring

• Power generation and energy systems

• Industrial control panels using 125VDC logic

• OEM automation with long-range DC sensors or switches

Why Choose the IC694MDL753?

• 125VDC Input Capability: Ideal for utility and industrial environments

• Group Isolation: Minimizes cross-talk and enhances safety

• Compact Footprint: High input density in a single-slot design

• Built-In Diagnostics: LED indicators for fast troubleshooting

Order Now

The GE Fanuc IC694MDL753 is available for fast global delivery.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
