GE Fanuc IC694MDL741 | RX3i 24VDC Discrete Output Module | 32 Points | Sourcing Outputs

Overview

The GE Fanuc IC694MDL741 is a 32-point 24VDC discrete output module designed for the PACSystems RX3i series. It provides positive logic (sourcing) outputs, ideal for driving DC-powered loads such as indicators, relays, solenoids, and other actuators. The outputs are organized into four isolated groups of eight, providing greater wiring flexibility and electrical isolation.

Key Features

• Output Type: 24VDC sourcing (positive logic)

• Number of Outputs: 32 (4 groups of 8 outputs)

• Output Current: Up to 0.5A per point

• Total Current per Group: 3A max

• Group Isolation: Electrically isolated from each other and system logic

• Protection: Overload and short-circuit protection

• Status Indicators: 32 green LEDs (1 per output)

• Hot-Swappable: Yes (in supported RX3i systems)

Technical Specifications

• Model Number: IC694MDL741

• Operating Voltage Range: 19.2–28.8 VDC

• Nominal Voltage: 24VDC

• Max Current per Point: 0.5A

• Max Current per Group: 3.0A

• Output Leakage (OFF): <0.1 mA

• ON Voltage Drop: <0.3 V @ rated load

• Power Requirements: 5V at 160 mA

• Isolation Voltage: 250V between groups and logic

• Operating Temperature: 0°C to 60°C

• Certifications: UL, CE

Applications

• Driving relays, solenoids, and contactors in DC systems

• Control of pilot lights and indicators

• High-density industrial control panels

• OEM equipment and automated machinery

Why Choose the IC694MDL741?

• High Output Density: 32 channels in a compact module

• Flexible Grouping: Four isolated groups for versatile wiring

• Industrial Durability: Engineered for reliable 24VDC load switching

• Diagnostic LEDs: Fast and easy output status monitoring
