GE IC694MDL660

GE Fanuc IC694MDL660 | RX3i Discrete Output Module | 16 Points | 125VDC Sourcing Outputs | Group-Isolated

Overview

The GE Fanuc IC694MDL660 is a 16-point discrete output module designed for use with the PACSystems RX3i series. It features sourcing (positive logic) outputs rated for 125VDC, making it ideal for controlling high-voltage DC loads in industrial applications. The outputs are organized into two isolated groups of 8, improving system flexibility and protection.

Key Features

• Output Type: 125VDC sourcing (positive logic)

• Number of Outputs: 16 (2 groups of 8 outputs)

• Current Rating: Up to 0.5A per point

• Group Isolation: Electrically isolated from each other and system logic

• Protection: Overcurrent and short-circuit protection

• Status Indicators: 16 green LEDs (1 per output)

• Hot-Swappable: Yes (in supported RX3i racks)

Technical Specifications

• Model Number: IC694MDL660

• Nominal Output Voltage: 125VDC

• Voltage Range: 100–150VDC

• Current per Output: 0.5A max

• ON Voltage Drop: <0.3V @ rated current

• OFF-State Leakage: <0.1 mA

• Power Requirements: 5V @ 160 mA

• Isolation Voltage: 250V between groups and logic

• Operating Temperature: 0°C to 60°C

• Certifications: UL, CE

Applications

• High-voltage DC output control for solenoids, contactors, or lamps

• Power generation and utility automation

• Industrial machinery with 125VDC logic

• OEM systems requiring group-isolated, high-voltage DC switching

Why Choose the IC694MDL660?

• High-Voltage Output Capability: Designed for 125VDC loads

• Group Isolation: Improves system safety and reliability

• Compact Design: 16 outputs in a single module

• Built-In Diagnostics: LED indicators for fast troubleshooting

Order Now

The GE Fanuc  IC694MDL660  output module is available and ready for immediate global shipment.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
