GE IC694MDL655

GE Fanuc IC694MDL655 | RX3i Discrete Input Module | 16 Points | 125VDC | Positive Logic | Group-Isolated

Overview

The GE Fanuc IC694MDL655 is a 16-point 125VDC discrete input module for the PACSystems RX3i platform. It accepts positive logic signals from field devices and is designed for industrial systems that operate with high-voltage DC control circuits. The inputs are organized in two isolated groups of 8 channels, improving noise immunity and application flexibility.

Key Features

• Input Type: 125VDC, positive logic (sinking input devices)

• Channels: 16 (2 groups of 8 inputs)

• Status Indicators: 16 green LEDs (one per input)

• Group Isolation: Electrically isolated from logic and between groups

• Hot-Swappable: Yes (when used in supported RX3i racks)

Technical Specifications

• Model Number: IC694MDL655

• Input Voltage Range: 0–150VDC

• On-State Voltage: 85–150VDC

• Off-State Voltage: 0–30VDC

• On-State Current (typ): 2.3 mA

• Off-State Current (max): 1.1 mA

• Input Delay: Typical 7 ms ON/OFF

• Power Requirements: 5V @ 80 mA

• Isolation Voltage: 250V between field and logic

• Operating Temperature: 0°C to 60°C

• Certifications: UL, CE

Applications

• Monitoring high-voltage DC inputs in utility or industrial systems

• Control panels using 125VDC logic devices

• OEM equipment with sourcing sensors or switches

• Environments requiring reliable signal isolation and diagnostics

Why Choose the IC694MDL655?

• High-Voltage Input Support: Built for 125VDC field signal monitoring

• Compact and Reliable: 16 inputs in a space-saving module

• Group Isolation: Reduces electrical interference

• Easy Diagnostics: Individual input status LEDs

Order Now

The GE Fanuc IC694MDL655 is available and ready to ship worldwide.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
