GE IC694MDL350

GE Fanuc IC694MDL350 | RX3i Discrete Output Module | 8 Points | Relay Outputs | 2A per Point | Isolated Channels

Overview

The GE Fanuc IC694MDL350 is an 8-point discrete relay output module designed for use with the PACSystems RX3i series. Each of the eight Form A (SPST-NO) relay contacts can switch AC or DC loads up to 2 amps, and the outputs are individually isolated to support mixed-voltage applications and improve electrical noise immunity.

Key Features

• Output Type: Relay (Form A, SPST-NO)

• Number of Outputs: 8 individually isolated channels

• Switching Capability: Up to 2A per point, AC or DC loads

• Status Indicators: 8 green LEDs (1 per output)

• Hot-Swappable: Yes (when used in supported RX3i racks)

• Isolation: Each output isolated from others and logic

Technical Specifications

• Model Number: IC694MDL350

• Max Voltage: 250VAC / 30VDC

• Max Current per Output: 2A (resistive load)

• Minimum Load: 10 mA @ 5VDC

• Relay Contact Life: 100,000 operations at rated load

• Power Requirements: 5V @ 110 mA

• Surge Current: 5A (one cycle)

• Operating Temperature: 0°C to 60°C

• Certifications: UL, CE

Applications

• Switching AC and DC devices such as solenoids, alarms, and contactors

• Industrial automation requiring isolated outputs

• Mixed-voltage control systems

• OEM control panels using RX3i PACSystems

Why Choose the IC694MDL350?

• Relay Flexibility: Supports both AC and DC load switching

• Isolated Outputs: Reduces interference, supports mixed-voltage wiring

• Compact Form Factor: 8 relays in a single-slot module

• Built-In LEDs: Simplifies troubleshooting and diagnostics

Order Now

The GE Fanuc IC694MDL350 relay output module is in stock and available for global shipping.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
