GE Fanuc IC694MDL241 | RX3i 24VDC Discrete Output Module | 16 Points | Sourcing Outputs

Overview

The GE Fanuc IC694MDL241 is a 16-point discrete output module designed for use with the PACSystems RX3i platform. It delivers 24VDC sourcing outputs (positive logic), ideal for driving solenoids, indicators, and relays in industrial DC applications. The outputs are arranged in two isolated groups of eight, allowing for flexible wiring and improved noise immunity.

Key Features

• Output Type: 24VDC sourcing (positive logic)

• Output Channels: 16 (2 isolated groups of 8)

• Current per Output: Up to 0.5A per point

• Total Module Load: Up to 4A per group

• Protection: Overcurrent and short-circuit protected

• Indicators: 16 LEDs (1 per channel) for output status

• Hot-Swappable: Yes (when used in RX3i systems)

Technical Specifications

• Model Number: IC694MDL241

• Voltage Range: 19.2–28.8 VDC

• Nominal Voltage: 24 VDC

• Output Current (max): 0.5A per channel, 4A max per group

• Minimum Load Current: 1 mA

• Voltage Drop (ON): <0.25 V at rated load

• Isolation: 250V between groups and logic

• Power Requirements: 5V at 130 mA

• Operating Temperature: 0°C to 60°C

• Certifications: UL, CE

Applications

• DC-powered relay control

• Solenoid and actuator control

• Panel indicators and pilot lamps

• Machine control in OEM and industrial automation systems

Why Choose the IC694MDL241?

• Reliable Sourcing Outputs: Supports positive logic DC loads

• Group Isolation: Greater flexibility and electrical protection

• Diagnostic LEDs: Easy channel-level troubleshooting

• Compact Design: 16 outputs in a single-slot module

Order Now

The GE Fanuc IC694MDL241 output module is available and ready to ship worldwide.
