GE IC694APU300

GE Fanuc IC694APU300 | RX3i High-Speed Counter Module | 2 Channels | 500 kHz Input | Discrete & Pulse Output

Overview

The GE Fanuc IC694APU300 is a 2-channel high-speed counter (HSC) module for the PACSystems RX3i series. Designed for applications requiring fast and accurate counting, it supports input frequencies up to 500 kHz and includes pulse and discrete output channels for real-time control of position, speed, and motion-based equipment.

Key Features

• Input Channels: 2 independent high-speed counters

• Max Input Frequency: 500 kHz

• Output Channels:

  • 2 Pulse outputs

  • 4 Discrete outputs

• Counting Modes: Up/down, quadrature, pulse/direction, and more

• Status Indicators: Front-panel LEDs for inputs and outputs

• Hot-Swappable: Yes (in compatible RX3i racks)

Technical Specifications

• Model Number: IC694APU300

• Input Voltage Range: 5–24VDC

• Input Type: Differential or single-ended

• Output Type: Open-drain (sink)

• Output Voltage: Up to 30VDC

• Output Current: 200 mA max per point

• Update Rate: Sub-millisecond response

• Power Requirements: 5V @ 160 mA, 24V @ 180 mA

• Operating Temperature: 0°C to 60°C

• Certifications: UL, CE

Applications

• Position and speed control in motion systems

• Encoder-based feedback applications

• High-speed counting in packaging, labeling, and bottling

• OEM automation requiring precision event detection

Why Choose the IC694APU300?

• Fast, Accurate Counting: Up to 500 kHz input support

• Flexible I/O Configuration: Discrete and pulse output channels

• Ideal for Motion Control: Designed for industrial automation timing tasks

• Diagnostics Built-In: LED indicators aid in setup and troubleshooting

Order Now

The GE Fanuc IC694APU300 is in stock and available for immediate global shipping.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
