GE IC694ALG223

GE Fanuc IC694ALG223 | RX3i Analog Input Module | 4 Channels | 4–20mA / 0–20mA | Current Input | Group-Isolated

Overview

The GE Fanuc IC694ALG223 is a 4-channel analog current input module for the PACSystems RX3i series. It accepts 0–20mA and 4–20mA current signals, making it ideal for monitoring sensors, transmitters, and industrial instrumentation in process control environments. All four inputs are group-isolated from the RX3i backplane and system logic.

Key Features

• Input Type: Analog current (0–20mA or 4–20mA)

• Channels: 4 (group-isolated)

• Resolution: 15-bit A/D conversion

• Accuracy: ±0.15% of full scale

• Configurable Ranges: Per channel via configuration software

• Diagnostics: Overrange, underrange, open-wire detection

• Hot-Swappable: Yes (in supported RX3i racks)

Technical Specifications

• Model Number: IC694ALG223

• Input Ranges:

  • 0–20mA

  • 4–20mA

• Input Impedance: 250 Ohms

• Resolution: 15 bits

• Update Rate: <2 ms per channel

• Power Requirements: 5V @ 80 mA, 24V @ 65 mA

• Operating Temperature: 0°C to 60°C

• Certifications: UL, CE, RoHS

Applications

• Monitoring of analog transmitters and sensors

• Process control systems using current loop input

• Industrial automation and OEM systems

• Distributed I/O configurations for analog data acquisition

Why Choose the IC694ALG223?

• Current Loop Compatibility: Supports industry-standard 4–20mA signals

• High Accuracy & Resolution: 15-bit analog conversion

• Reliable Diagnostics: Built-in error and signal monitoring

• Group Isolation: Protects system integrity and reduces noise

Order Now

The GE Fanuc IC694ALG223 is in stock and ready for worldwide delivery.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
