GE IC694ALG221

GE Fanuc IC694ALG221 | RX3i Analog Output Module | 2 Channels | 0–10V / ±10V | Voltage Output

Overview

The GE Fanuc IC694ALG221 is a 2-channel analog voltage output module for the PACSystems RX3i series. It provides precise voltage signals of 0–10V or ±10V to control external devices like drives, actuators, or instrumentation. With 12-bit resolution and channel-level configuration, it's ideal for industrial automation requiring accurate analog voltage control.

Key Features

• Output Type: Analog voltage (0–10V or ±10V)

• Channels: 2 independently configurable channels

• Resolution: 12-bit D/A conversion

• Channel Isolation: Not individually isolated (grouped)

• Status Indicators: Module-level diagnostics

• Hot-Swappable: Yes (in supported RX3i configurations)

Technical Specifications

• Model Number: IC694ALG221

• Output Voltage Ranges:

  • 0 to 10V

  • –10 to +10V

• Resolution: 12 bits

• Load Resistance: ≥2 kΩ

• Accuracy: ±0.3% of full scale

• Update Rate: <2 ms

• Power Requirements: 5V @ 80 mA, 24V @ 60 mA

• Operating Temperature: 0°C to 60°C

• Certifications: UL, CE

Applications

• Analog voltage control for VFDs, drives, and actuators

• Output to analog indicators and measurement systems

• Industrial machinery requiring voltage feedback

• OEM systems with voltage-controlled components

Why Choose the IC694ALG221?

• Voltage Signal Flexibility: Choose 0–10V or ±10V per channel

• High Accuracy & Speed: Suitable for precision automation control

• Compact Design: 2 channels in a single-slot RX3i format

• Industrial Reliability: Designed for rugged environments

Order Now

The GE Fanuc IC694ALG221 voltage output module is available for fast global shipping.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
