GE IC693MDL741

GE Fanuc IC693MDL741 | Series 90-30 Discrete Output Module | 12/24VDC | 16 Points | Positive Logic (Sourcing)

Overview

The GE Fanuc IC693MDL741 is a 16-point discrete output module for the Series 90-30 PLC platform, designed for 12/24VDC positive logic (sourcing) outputs. This module is ideal for controlling a variety of DC-powered field devices like solenoids, lamps, and contactors. It features built-in electronic protection and LED indicators for real-time output status monitoring.

Key Features

• Output Type: Discrete DC, positive logic (sourcing)

• Voltage Range: 12 or 24 VDC

• Output Channels: 16 (grouped into 2 isolated groups of 8)

• Status Indicators: One LED per output

• Protection: Short-circuit and overload protection

• Backplane Compatibility: Designed for Series 90-30 PLC racks

Technical Specifications

• Model Number: IC693MDL741

• Nominal Voltage: 12 or 24VDC

• Voltage Range: 5–30VDC

• Max Output Current:

  • 0.5A per point

  • 2A per group

  • 4A total per module

• On-State Voltage Drop: ≤ 1.0V at rated current

• Response Time: < 0.2 ms

• Power Requirements: 5V @ 120 mA

• Isolation: 1500V field-to-logic

• Operating Temperature: 0°C to 60°C

• Certifications: UL, CE, RoHS

Applications

• Controlling DC field devices with positive logic requirements

• OEM and industrial automation systems

• Series 90-30 PLC-based control panels

• High-density output modules for distributed control

Why Choose the IC693MDL741?

• Flexible Voltage Use: Supports both 12V and 24VDC systems

• High Output Density: 16 outputs in a single module

• Built-In Diagnostics: LED indicators simplify troubleshooting

• Reliable GE Design: Designed for Series 90-30 performance and durability

Order Now

The GE Fanuc IC693MDL741 output module is in stock and ready for fast global shipping.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
