GE IC693MDL646

GE Fanuc IC693MDL646 | Series 90-30 Discrete Output Module | 24VDC | 16 Points | Negative Logic (Sinking)

Overview

The GE Fanuc IC693MDL646 is a 16-point discrete output module for the Series 90-30 PLC system, designed for 24VDC sinking (negative logic) outputs. It is ideal for controlling field devices that require a connection to ground through the output module. Each output is electronically protected and features individual status LEDs for real-time diagnostics.

Key Features

• Output Type: Discrete, 24VDC sinking (negative logic)

• Output Channels: 16 outputs (2 isolated groups of 8)

• Status Indicators: One LED per output

• Electronic Protection: Short-circuit and overload protection

• High-Density Output: Compact design with high point count

Technical Specifications

• Model Number: IC693MDL646

• Voltage Range: 5–30VDC

• Max Output Current:

  • 0.5A per point

  • 2A per group

  • 4A total per module

• On-State Voltage Drop: ≤ 1.0V at rated load

• Response Time: < 0.2 ms

• Power Requirements: 5V @ 120 mA (from backplane)

• Isolation: 1500V field-to-logic

• Operating Temperature: 0°C to 60°C

• Certifications: UL, CE, RoHS

Applications

• Industrial automation with sinking-type field devices

• Solenoids, relays, alarms, and other 24VDC actuators

• OEM machinery using Series 90-30 PLCs

• High-density discrete output control panels

Why Choose the IC693MDL646?

• Negative Logic Control: Ideal for field devices requiring a path to ground

• High Output Count: 16 points in a single module

• Built-In Diagnostics: Status LEDs streamline troubleshooting

• Reliable Performance: Designed for industrial-grade automation

Order Now

The GE Fanuc IC693MDL646 discrete output module is available and ready for fast worldwide shipping.
