GE Fanuc IC693MDL645 | Series 90-30 Discrete Output Module | 24VDC | 16 Points | Positive Logic (Sourcing)

Overview

The GE Fanuc IC693MDL645 is a 16-point discrete output module designed for the Series 90-30 PLC system, offering 24VDC positive logic (sourcing) outputs. It is used to control field devices such as relays, solenoids, and lamps. The module includes built-in short-circuit protection and status LEDs for each output, making it suitable for reliable and efficient output control in industrial environments.

Key Features

• Output Voltage: 24VDC nominal

• Logic Type: Positive logic (sourcing outputs)

• Number of Outputs: 16 channels (2 groups of 8)

• Status LEDs: One per channel

• Electronic Protection: Overcurrent and short-circuit protection

• Backplane Communication: Standard Series 90-30 interface

Technical Specifications

• Model Number: IC693MDL645

• Voltage Range: 5–30VDC

• On-State Voltage Drop: <1.0V at 0.5A load

• Max Output Current:

  • 0.5A per point

  • 4A per group

  • 8A max per module

• Response Time: 0.2 ms typical

• Power Consumption: 5V @ 100 mA (from backplane)

• Isolation: 1500V field-to-logic isolation

• Operating Temperature: 0°C to 60°C

• Certifications: UL, CE, RoHS

Applications

• 24VDC discrete device control (lamps, solenoids, relays)

• OEM machine control using Series 90-30 PLCs

• Industrial automation systems requiring sourcing outputs

• Systems needing LED feedback and output protection

Why Choose the IC693MDL645?

• High-Density Outputs: 16 points in a single module

• Built-In Protection: Overcurrent and short-circuit safeguards

• Status Monitoring: LEDs on each output for quick diagnostics

• Seamless Integration: Fully compatible with Series 90-30 racks and CPUs

Order Now

The GE Fanuc IC693MDL645 output module is in stock and ready for fast worldwide shipping.
