GE IC693MDL231

GE Fanuc IC693MDL231 | Series 90-30 Discrete Input Module | 24VDC | 16-Point Input | Positive Logic

Overview

The GE Fanuc IC693MDL231 is a 16-point discrete input module for the Series 90-30 PLC platform, supporting 24VDC positive logic inputs. It provides reliable signal detection from field devices such as sensors, push buttons, and switches. The module features fast input response and individual LED status indicators for each channel, making it ideal for monitoring real-time industrial signals.

Key Features

• Input Voltage: 24VDC nominal

• Logic Type: Positive logic (sourcing input devices)

• Input Points: 16 channels (grouped into 2 sets of 8)

• Status Indicators: Individual LEDs per input

• Input Isolation: Group-to-logic isolation for signal protection

• Fast Response Time: ~1 ms typical

Technical Specifications

• Model Number: IC693MDL231

• Voltage Range: 0–30 VDC

• On-State Voltage: ≥ 11 VDC

• Off-State Voltage: ≤ 5 VDC

• On-State Current: ≥ 3 mA

• Off-State Current: ≤ 1.1 mA

• Power Consumption: 5V @ 80 mA from backplane

• Isolation: 1500V (group-to-logic)

• Operating Temperature: 0°C to 60°C

• Certifications: UL, CE, RoHS

Applications

• Monitoring 24VDC sensors and switches

• Industrial machine and process control systems

• Distributed I/O and OEM panel integration

• Series 90-30-based automation requiring fast and reliable digital input

Why Choose the IC693MDL231?

• 24VDC Standard: Common industrial control voltage

• Compact Design: 16 inputs in a single module

• Built-In LEDs: Quick input diagnostics

• GE Reliability: Fully compatible with Series 90-30 systems

Order Now

The GE Fanuc IC693MDL231 discrete input module is in stock and ready for fast global shipping.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
