GE IC693ALG442

GE Fanuc IC693ALG442 | Series 90-30 Analog Output Module | 4 Channels | 0–10VDC or 4–20mA | 12-Bit Resolution | Isolated Outputs

Overview

The GE Fanuc IC693ALG442 is a versatile 4-channel analog output module for the Series 90-30 PLC system, supporting both 0–10VDC and 4–20mA output signals. With 12-bit resolution and individually isolated channels, this module is ideal for precise analog control of field devices such as actuators, drives, and valves.

Key Features

• Output Channels: 4 individually isolated outputs

• Signal Ranges:

  • 0–10VDC

  • 4–20mA

• Resolution: 12-bit (1 in 4096 steps)

• Output Isolation: 1500V channel-to-logic and channel-to-channel

• Status Indicators: LEDs for module status

Technical Specifications

• Model Number: IC693ALG442

• Load Resistance:

  • Voltage: ≥ 2 kΩ

  • Current: ≤ 750 Ω

• Accuracy: ±0.3% of full scale

• Response Time: < 1 ms typical

• Power Requirements:

  • 5V @ 80 mA

  • 24V @ 160 mA

• Operating Temperature: 0°C to 60°C

• Configuration: Via Proficy Machine Edition or Logicmaster 90

• Certifications: UL, CE, RoHS

Applications

• Analog control of actuators, drives, and proportional valves

• Process control requiring voltage or current output

• OEM automation and industrial panel solutions

• Mixed analog signal generation in Series 90-30 systems

Why Choose the IC693ALG442?

• Dual Output Modes: Supports both voltage and current devices

• Isolated Channels: Reduces noise and increases signal reliability

• Compact Design: 4 channels in a single slot

• GE Fanuc Reliability: Built for demanding industrial environments

Order Now

The GE Fanuc IC693ALG442 analog output module is in stock and ready for fast international shipping.
