GE IC693ALG223

GE Fanuc IC693ALG223 | Series 90-30 Analog Output Module | 4 Channels | 4–20mA Current Output | 12-Bit Resolution | Isolated Outputs

Overview

The GE Fanuc IC693ALG223 is a 4-channel analog output module designed for the Series 90-30 PLC system, delivering precise 4–20mA current signals to control actuators, valves, drives, and other current-loop-compatible field devices. Each output channel is electrically isolated, providing high accuracy and system reliability.

Key Features

• Output Type: Analog current

• Signal Range: 4–20mA

• Channels: 4 individually isolated outputs

• Resolution: 12-bit (1 in 4096 steps)

• Output Isolation: 1500V field-to-logic and channel-to-channel

• Status Indicators: Module-level diagnostics LEDs

Technical Specifications

• Model Number: IC693ALG223

• Output Load Resistance: 0–750 ohms

• Accuracy: ±0.3% of full scale

• Response Time: <1 ms typical

• Power Requirements:

  • 5V @ 80 mA

  • 24V @ 160 mA

• Operating Temperature: 0°C to 60°C

• Certifications: UL, CE, RoHS

• Configuration: Via Proficy Machine Edition or Logicmaster 90

Applications

• Process control with 4–20mA instrumentation

• Analog signal generation for current-loop actuators

• OEM equipment requiring precise analog output control

• Series 90-30 PLC-based systems with analog I/O needs

Why Choose the IC693ALG223?

• High Precision: 12-bit resolution for smooth control

• Isolated Outputs: Reduces electrical interference and increases safety

• Standard Output Signal: 4–20mA compatible with most industrial devices

• GE Fanuc Reliability: Long-term performance in demanding environments

Order Now

The GE Fanuc IC693ALG223 analog output module is in stock and available for fast international shipping.

Return to GE IC693 PLC Series 90-30 for more options in this series.

 Explore our full range of GE Industrial Automation Products to find PLCs, HMIs, servo drives, control modules, and other automation solutions.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
