GE IC693ALG222

GE Fanuc IC693ALG222 | Series 90-30 Analog Output Module | 2 Channels | 4–20mA Current Output | 12-Bit Resolution | Isolated Outputs

Overview

The GE Fanuc IC693ALG222 is a 2-channel analog output module designed for the Series 90-30 PLC system, providing 4–20mA current signals to control field devices such as actuators, valves, or transmitters. With 12-bit resolution and electrically isolated outputs, this module ensures stable and accurate signal generation in industrial automation environments.

Key Features

• Output Type: Analog current

• Signal Range: 4–20mA

• Channels: 2 individually isolated outputs

• Resolution: 12-bit (1 in 4096 steps)

• Output Isolation: 1500V field-to-logic isolation

• Status Indicators: Module power and health LEDs

Technical Specifications

• Model Number: IC693ALG222

• Output Load Resistance: 0–750 ohms

• Accuracy: ±0.3% of full scale

• Power Requirements:

  • 5V @ 75 mA

  • 24V @ 130 mA

• Response Time: <1 ms typical

• Operating Temperature: 0°C to 60°C

• Certifications: UL, CE, RoHS

Applications

• Industrial process control using 4–20mA actuators

• Flow, level, or pressure control with analog output devices

• OEM machinery requiring reliable current-loop control

• Integration into Series 90-30 PLC systems for analog signal generation

Why Choose the IC693ALG222?

• Industry Standard Output: 4–20mA widely supported by industrial equipment

• Isolated Channels: Enhances system protection and signal integrity

• GE Fanuc Reliability: Built for demanding industrial environments

• Easy Integration: Plug into any Series 90-30 I/O baseplate

Order Now

The GE Fanuc IC693ALG222 analog output module is available and ready for fast international shipping.
