GE IC200UEX636

GE Fanuc IC200UEX636 | VersaMax Nano I/O Expansion Module

Overview

The IC200UEX636 is a VersaMax Nano I/O expansion unit by GE Fanuc, designed to extend the input/output capacity of VersaMax Nano PLC systems. Featuring 16 discrete 24 VDC inputs and 16 relay outputs, this module is ideal for applications that require reliable, compact, and cost-effective digital I/O expansion.

Key Features

• Input Channels: 16 DC inputs (24 VDC sink/source compatible)

• Output Channels: 16 relay outputs (dry contact)

• Input Voltage: 24 VDC

• Output Type: Form A relay contacts (SPST-NO)

• Isolation: Input-to-output and channel-to-channel relay isolation

• Mounting: DIN rail or panel mount

• Indicators: LED status for inputs and outputs

Technical Specifications

• Model Number: IC200UEX636

• Input Voltage Range: 18–30 VDC

• Output Voltage Rating: 30 VDC / 250 VAC max

• Relay Contact Current: 2 A per channel (resistive load)

• Power Consumption: Approx. 1.5 W

• Operating Temperature: 0°C to 55°C

• Dimensions (W x H x D): ~90 mm x 100 mm x 70 mm

• Weight: Approx. 0.45 kg

• Certifications: UL, CE

Applications

• Machine Automation: Expand control capabilities of VersaMax Nano PLCs

• Material Handling Systems: Reliable relay switching for actuators and sensors

• Industrial Control Panels: Compact digital I/O for modular designs

• OEM Equipment: Ideal for embedded systems requiring scalable I/O

Why Choose the IC200UEX636?

• Versatile I/O Expansion: Adds 32 channels in a compact footprint

• Field-Proven Design: Trusted in industrial environments worldwide

• Easy Integration: Seamless with existing VersaMax Nano PLCs

• Relay Isolation: Enhances protection and device longevity

• Cost-Effective: Low-cost expansion without sacrificing reliability

Order Now

The GE IC200UEX636 is available for fast shipping.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
