GE 8104-AO-IP

GE 8104-AO-IP | 4-Channel Isolated Analog Output Module for PAC8000

Overview

The GE 8104-AO-IP is a 4-channel isolated analog output module designed for the PAC8000 I/O platform. It provides precise current loop signals (4–20 mA) for controlling actuators, valves, and other process equipment in both general-purpose and hazardous area applications. Each channel is isolated to ensure high noise immunity and reliable operation in harsh industrial environments.

Key Features

• Analog Outputs: 4 individually isolated channels

• Output Signal Range: 4–20 mA (source)

• Isolation: 250V RMS channel-to-channel and channel-to-backplane

• Update Rate: 2 outputs updated per scan

• Resolution: 12-bit D/A conversion

• Diagnostics: Open-wire detection and status reporting

• Compliance Voltage: 11V (minimum)

• Mounting: DIN rail-compatible carrier

• Temperature Range: -40°C to +70°C

• Hazardous Location Rating: Class I, Div 2 / Zone 2 certified

Technical Specifications

• Model Number: 8104-AO-IP

• Power Supply: 24 VDC field supply

• Output Load: 250–600 Ohms (typical)

• Accuracy: ±0.1% full scale at 25°C

• Current Draw: ~60 mA max from backplane

• Dimensions: Approx. 168 mm (D) x 42 mm (W) x 37 mm (H)

• Weight: ~200 grams

• Approvals: UL, CE, ATEX, CSA

Applications

• Process Control Systems: Flow control, valve actuation, and dosing

• Industrial Automation: Precise analog control in manufacturing lines

• Oil & Gas / Chemical Plants: Certified for hazardous environments

• Building Automation: Analog output for HVAC and energy systems

Why Choose the 8104-AO-IP?

• High Reliability: Isolated outputs minimize signal interference

• Wide Compatibility: Seamlessly integrates with PAC8000 systems

• Precise Control: 12-bit resolution ensures accurate signal delivery

• Certified for Safety: Operates safely in hazardous classified areas

• Easy Diagnostics: Channel health monitored in real time

Order Now

The GE 8104-AO-IP analog output module is in stock and ready to ship.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
