Overview

The Beckhoff KL2541 is a Bus Terminal designed to generate pulse-width modulation (PWM) signals for controlling actuators, DC motors, or other loads. Operating with a 24 V DC supply and delivering up to 2.5 A, it provides precise speed and position control. Its compact design ensures easy integration into modular I/O systems.

Key Features

• 1 PWM output channel

• 24 V DC operating voltage

• Output current up to 2.5 A

• High-resolution PWM for precise control

• Integrated diagnostics and error reporting

• Compact size for DIN-rail installation

• Designed for motor, actuator, and valve control

Technical Specifications

• Part Number: KL2541

• Manufacturer: Beckhoff

• Channels: 1

• Output Voltage: 24 V DC

• Output Current: 2.5 A max

• Signal Type: PWM (Pulse-Width Modulation)

• Mounting: DIN rail terminal

• Operating Temperature: 0 °C to +55 °C

Applications

• DC motor control

• Valve and actuator operation

• Positioning systems

• Conveyor and feeder automation

• Laboratory and test equipment

Why Choose the KL2541

• High-precision PWM output for smooth control

• Compact and modular I/O integration

• Reliable operation with diagnostics and protection

• Cost-effective solution for motion and actuator control

Order Now

The Beckhoff KL2541 1-channel PWM output terminal is available and ships worldwide.
