Overview

The Beckhoff EL9505 is a power supply terminal that provides regulated 24 V DC power to the EtherCAT Terminal system bus. With an output of up to 0.5 A, it is ideal for smaller automation stations where reliable system bus power distribution is required.

Key Features

• Supplies 24 V DC to the EtherCAT system bus

• Output current up to 0.5 A

• Compact and modular design

• Integrated diagnostic LEDs for status monitoring

• Ensures reliable EtherCAT I/O operation

• Easy DIN-rail mounting

Technical Specifications

• Beckhoff Code: EL9505

• Type: Power Supply Terminal

• Input Voltage: 24 V DC

• Output Current: up to 0.5 A

• Electrical Isolation: Yes

• System Bus Supply: Yes

• Operating Temperature: 0 °C to +55 °C

• Mounting: DIN rail (EtherCAT modular system)

• Certifications: CE, UL

Applications

• Powering EtherCAT I/O terminals

• Compact automation systems

• Machine and process control

• Distributed I/O stations

• Modular PLC installations

Why Choose Beckhoff EL9505?

• Reliable 24 V DC bus supply up to 0.5 A

• Compact and efficient for small systems

• Seamless EtherCAT integration

• Proven Beckhoff quality and durability

Order Now

Equip your automation setup with the Beckhoff EL9505, delivering dependable 24 V DC system bus power in a compact design.
