Beckhoff EL7342

Beckhoff EL7342

Overview

The Beckhoff EL7342 is a 2-channel DC motor output terminal designed for controlling two DC motors up to 24 V DC. It uses pulse-width modulation (PWM) for precise speed and torque control, making it suitable for motion control tasks in automation systems. Integrated current measurement and overload protection enhance operational safety and reliability.

Key Features

• 2 independent DC motor outputs

• Supports 24 V DC motor voltage

• PWM control for precise speed regulation

• Integrated current measurement per channel

• Overload and short-circuit protection

• Compact 12 mm housing for space-saving installation

• EtherCAT-compatible for fast communication

Technical Specifications

• Part Number: EL7342

• Manufacturer: Beckhoff

• Channels: 2

• Motor Voltage: 24 V DC max

• Continuous Output Current: Up to 3.5 A per channel

• Control Method: PWM (Pulse Width Modulation)

• Mounting: DIN-rail terminal

• Housing Width: 12 mm

• Operating Temperature: –25 °C to +60 °C

Applications

• Small DC motor control

• Conveyor and feeder systems

• Automated machinery

• Laboratory automation

• Positioning and drive systems

Why Choose the EL7342

• Dual-channel DC motor control in a compact form

• High-precision PWM output for smooth operation

• Integrated protection for reliable performance

• Seamless integration with Beckhoff EtherCAT I/O systems

Order Now

The Beckhoff EL7342 2-channel DC motor output terminal is available and ships worldwide.
