Beckhoff EL7211-9014

Beckhoff EL7211-9014

Overview

The Beckhoff EL7211-9014 is a 1-channel EtherCAT servo terminal with an integrated One Cable Technology (OCT) drive for compact motion control. Delivering up to 2.8 A RMS output current, it is designed to control servomotors directly from the EtherCAT I/O system. This space-saving design eliminates the need for external servo drives, making it ideal for decentralized motion applications.

Key Features

• 1-channel servo terminal with integrated drive

• Continuous output current: 2.8 A RMS

• Supports Beckhoff servomotors with OCT (power + feedback in one cable)

• Compact EtherCAT terminal housing (12 mm width)

• Diagnostic LEDs for quick status monitoring

• Seamless integration with TwinCAT Motion Control software

• Electrical isolation between I/O and bus system

Technical Specifications

• Part Number: EL7211-9014

• Manufacturer: Beckhoff

• Type: EtherCAT servo terminal with OCT drive

• Channels: 1 servo axis

• Output Current: Up to 2.8 A RMS

• Supported Motors: Beckhoff servomotors with OCT

• Width: 12 mm

• Mounting: DIN rail (EtherCAT Terminal system)

• Operating Temperature: –25 °C to +60 °C

Applications

• Compact motion control in EtherCAT systems

• Robotics and handling systems

• Packaging and labeling machines

• CNC and machine tool automation

• Distributed drive control with reduced wiring (OCT)

Why Choose the EL7211-9014

• Integrates servo drive into the EtherCAT terminal system

• Supports One Cable Technology (OCT) for simplified wiring

• Compact 12 mm design saves control cabinet space

• Direct TwinCAT integration for motion control programming

• Proven Beckhoff EtherCAT servo performance

Order Now

The Beckhoff EL7211-9014 EtherCAT servo terminal with 2.8 A RMS output and OCT support is available and ships worldwide.
