Beckhoff EL6652-0010

Beckhoff EL6652-0010

Overview

The Beckhoff EL6652-0010 is a communication terminal that enables the integration of PROFINET RT devices into an EtherCAT system. With two Ethernet ports, it functions as a PROFINET RT slave (device), allowing direct communication between EtherCAT controllers and PROFINET networks. This module simplifies hybrid automation systems where both fieldbus standards are used, providing seamless interoperability.

Key Features

• 2-port PROFINET RT device terminal

• Acts as a PROFINET RT slave within EtherCAT systems

• Seamless communication between EtherCAT and PROFINET networks

• Compact DIN-rail housing

• Diagnostic LEDs for connection and activity monitoring

• Supports real-time PROFINET communication

• Easy configuration via Beckhoff TwinCAT software

Technical Specifications

• Part Number: EL6652-0010

• Manufacturer: Beckhoff

• Protocol: PROFINET RT (slave/device)

• Ports: 2 × RJ45 Ethernet

• Bus Interface: EtherCAT

• Housing Width: 24 mm

• Mounting: DIN-rail terminal

• Operating Temperature: –25 °C to +60 °C

• Isolation: 500 V (system to field)

Applications

• Integration of PROFINET devices into EtherCAT networks

• Hybrid automation systems using multiple fieldbus standards

• Machine and process automation

• Packaging, logistics, and material handling equipment

• Industrial communication gateways

Why Choose the EL6652-0010

• Provides seamless interoperability between EtherCAT and PROFINET RT

• Compact design with dual-port flexibility

• Real-time performance ensures reliable communication

• Easy configuration with TwinCAT for fast deployment

Order Now

The Beckhoff EL6652-0010 PROFINET RT device terminal is available and ships worldwide.
