Overview

The Beckhoff EL5151 is a 1-channel encoder interface terminal designed for connecting encoders with SSI (Synchronous Serial Interface) to EtherCAT systems. It enables high-precision position and motion feedback, making it essential in automation, robotics, and machine control applications. The module supports a wide range of SSI encoders and provides real-time data acquisition for accurate motion control.

Key Features

• 1 SSI encoder interface channel

• Supports various encoder resolutions

• High-precision position and motion feedback

• Fast EtherCAT communication

• Diagnostic LEDs for encoder status monitoring

• Compact 12 mm housing for space efficiency

• Seamless integration with Beckhoff I/O system

Technical Specifications

• Part Number: EL5151

• Manufacturer: Beckhoff

• Channels: 1 encoder input (SSI)

• Encoder Type: SSI (Synchronous Serial Interface)

• Data Rate: Up to 1 MHz

• Isolation: 500 V (system to field)

• Housing Width: 12 mm

• Mounting: DIN-rail terminal

• Operating Temperature: –25 °C to +60 °C

Applications

• Motion control and positioning systems

• Robotics and automation

• Conveyor and packaging equipment

• CNC machinery

• Industrial process control requiring encoder feedback

Why Choose the EL5151

• Accurate encoder data acquisition via SSI

• Compact design saves panel space

• Reliable EtherCAT communication

• Widely compatible with industrial SSI encoders

Order Now

The Beckhoff EL5151 1-channel encoder interface terminal is available and ships.
