Beckhoff EL4122

Beckhoff EL4122

Overview

The Beckhoff EL4122 is a 2-channel analog output terminal for the EtherCAT I/O system. It outputs voltage signals in the range of ±10 V with a resolution of 16 bits, ensuring precise and reliable analog control in automation tasks. With its compact design and seamless integration into EtherCAT networks, the EL4122 is ideal for machine and process automation.

Key Features

• 2 analog output channels

• Output voltage range: ±10 V

• High precision with 16-bit resolution

• Electrical isolation between I/O and bus system

• Compact 12 mm EtherCAT terminal design

• Integrated diagnostic LEDs

• Full integration with Beckhoff TwinCAT software

Technical Specifications

• Part Number: EL4122

• Manufacturer: Beckhoff

• Channels: 2 analog outputs

• Output Range: ±10 V

• Resolution: 16-bit

• Max Output Current: 10 mA per channel

• Electrical Isolation: 500 V (I/O to bus system)

• Housing Width: 12 mm

• Mounting: DIN rail (EtherCAT Terminal system)

• Operating Temperature: –25 °C to +60 °C

Applications

• Analog control in process automation

• Machine automation requiring voltage outputs

• Signal generation for test benches and laboratories

• Building and energy automation systems

• Distributed EtherCAT I/O with analog output capability

Why Choose the EL4122

• Compact 2-channel ±10 V analog output terminal

• High accuracy with 16-bit resolution

• Reliable performance with electrical isolation

• Seamless EtherCAT integration for real-time control

• Backed by Beckhoff’s proven quality and TwinCAT compatibility

Order Now

The Beckhoff EL4122 2-channel analog output terminal is available and ships worldwide.
