Overview

The Beckhoff EL3201 is a 1-channel analog input terminal for direct connection of RTD sensors (PT100). With a 16-bit resolution, it provides highly accurate temperature acquisition in automation systems. As part of the EtherCAT I/O system, the EL3201 offers fast communication, integrated diagnostics, and simple configuration with TwinCAT software.

Key Features

• 1 RTD input channel

• Direct connection for PT100 sensors

• 16-bit resolution for high measurement accuracy

• Compact 12 mm EtherCAT housing

• Integrated diagnostic LEDs

• Electrical isolation between I/O and bus system

• Seamless integration with TwinCAT automation software

Technical Specifications

• Part Number: EL3201

• Manufacturer: Beckhoff

• Function: RTD analog input terminal

• Channels: 1 input

• Sensor Type: RTD (PT100)

• Resolution: 16-bit

• Electrical Isolation: Yes (I/O to E-bus)

• Housing Width: 12 mm

• Mounting: DIN rail (EtherCAT Terminal system)

• Operating Temperature: –25 °C to +60 °C

Applications

• Temperature measurement with PT100 sensors

• Machine and process automation

• Building and energy monitoring systems

• Laboratory and test automation

• Distributed EtherCAT I/O architectures

Why Choose the EL3201

• Compact single-channel RTD measurement solution

• High accuracy with 16-bit resolution

• Direct PT100 sensor connection without external converters

• Integrated diagnostics for reliable operation

• Backed by Beckhoff EtherCAT technology

Order Now

The Beckhoff EL3201 RTD input terminal for PT100 sensors is available and ships worldwide.
