Balluff BES014W

Balluff BES014W

Balluff Code: BES M12EE-PSC40B-S04G

Overview

The Balluff BES014W is a robust inductive proximity sensor designed for industrial automation tasks requiring reliable and contactless object detection. With an M18 flush housing and 10 mm sensing range, it offers consistent switching performance and extended service life, even in demanding environments.

Key Features

• M18 × 1 flush-mounted housing

• 10 mm sensing distance

• PNP normally open (NO) output

• DC 3-wire configuration

• LED for clear status indication

• Short-circuit and overload protection

• Nickel-plated brass housing for durability

• IP67-rated for harsh environments

Technical Specifications

• Housing Size: M18 × 1

• Installation Type: Flush

• Sensing Distance: 10 mm

• Output Type: PNP NO

• Supply Voltage: 10–30 V DC

• Connection: M12 connector, 4-pin

• Housing Material: Nickel-plated brass

• Protection Rating: IP67

• Operating Temperature: –25 °C to +70 °C

Applications

• Object positioning and presence detection

• Automation of material handling systems

• Monitoring of mechanical parts in motion

• Packaging and bottling lines

• Robotics and conveyor applications

Why Choose Balluff BES014W?

• Reliable detection with 10 mm range

• Robust and resistant to environmental stress

• Easy integration with M12 connector

• Designed for maintenance-free, long-term use

• Proven performance in tough industrial settings

Order Now

Ensure accurate and contactless detection in your automation system with the Balluff BES014W — a rugged inductive sensor built for precision and endurance.
