Allen-Bradley 1797-IBN16 POINT I/O 16-Point Digital Input Module for Control Systems

Allen-Bradley 1797-IBN16 POINT I/O 16-Point Digital Input Module

The Allen-Bradley 1797-IBN16 is a POINT I/O 16-Point Digital Input Module, part of the POINT I/O series by Rockwell Automation. This module is designed to provide 16 digital input channels for industrial automation systems, ensuring reliable data transmission and control in various applications. The 1797-IBN16 module is ideal for connecting sensors, switches, and other field devices to Allen-Bradley control systems, such as ControlLogix or CompactLogix.

Technical Specifications:

• Part Number: 1797-IBN16
• Module Type: 16-Point Digital Input Module
• Input Voltage Range: 24V DC nominal
• Input Current: 3-7 mA per point
• Input Type: Sourcing or sinking digital inputs (configurable)
• Operating Voltage Range: 10-30V DC
• Isolation: 500V RMS channel-to-channel and channel-to-ground
• Power Consumption: 3.3W max
• Dimensions: 4.8 x 3.3 x 1.5 in. (121 x 84 x 38 mm)
• Weight: 0.4 lbs (0.18 kg)
• Operating Temperature Range: 0°C to 60°C (32°F to 140°F)
• Storage Temperature Range: -40°C to 85°C (-40°F to 185°F)
• Certifications: UL, CE, CSA, RoHS compliant
• Mounting: Panel mount or DIN rail

Key Features:

• 16 Digital Inputs: Supports 16 channels for sourcing or sinking digital inputs, offering flexibility for different industrial applications.
• Wide Voltage Range: Operates within a 10-30V DC input voltage range, making it compatible with a variety of field devices.
• High Isolation: 500V RMS isolation between channels and channel-to-ground ensures reliable protection from electrical interference.
• Compact Design: Space-efficient design allows for easy installation in control panels, optimizing available space in control systems.
• Diagnostics LED Indicators: Equipped with LED status indicators for quick diagnostics, helping operators monitor system health and performance.
• Easy Integration: Part of the POINT I/O system, which can be seamlessly integrated with ControlLogix and CompactLogix systems for scalable and flexible industrial automation solutions.

Applications:

• Industrial Automation: Connects sensors, switches, and other devices to Allen-Bradley control systems for automated manufacturing processes.
• Control Systems: Ideal for use in ControlLogix and CompactLogix systems, providing reliable data input for monitoring and control.
• Process Control: Used to gather input from digital sensors in process control applications for real-time control and monitoring.
• Machine Safety: Can be used in machine safety applications, helping to interface emergency stop buttons, limit switches, and safety interlocks.
• Factory Automation: Enhances factory automation systems, enabling precise and accurate control over connected devices and processes.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
