Allen-Bradley 100-DNY41R

Allen-Bradley 100-DNY41R | Distributed Starter System DSA

Overview:

The Allen-Bradley 100-DNY41R is a Distributed Starter Auxiliary (DSA) module engineered to facilitate the seamless integration of motor starters and sensors into a DeviceNet network. Equipped with 4 inputs at 120V AC and 2 relay outputs rated up to 250V, this module streamlines control and monitoring within industrial automation systems.

Please Note: As of September 30, 2021, the 100-DNY41R has been discontinued and is no longer available for sale. For migration options and replacement products, refer to the Rockwell Automation Migration Document.

Key Features:

• DeviceNet Integration: Simplifies the connection of motor starters and sensors to DeviceNet networks, enhancing system communication and control.
• Input Configuration: Four 120V AC inputs designed for standard industrial signal levels.
• Output Configuration: Two relay outputs capable of switching up to 250V, suitable for controlling various actuators and devices.
• Compact Design: Facilitates easy installation within control panels, optimizing space utilization.
• Diagnostic Indicators: Equipped with LED status indicators for inputs, outputs, and network status, aiding in efficient troubleshooting and maintenance.

Technical Specifications:

• Model: 100-DNY41R
• Inputs: 4 channels at 120V AC
  • Voltage Range: 80…132V AC
  • On-State Current: 2 mA maximum
  • Off-State Voltage: 40V AC maximum
• Outputs: 2 relay channels
  • Voltage Range: Up to 240V AC or 30V DC
  • Switching Capacity: 3600 VA maximum
  • Thermal Continuous Current: 5 A per output
• Network Interface: DeviceNet compatible
  • Baud Rates Supported: 125 kbps, 250 kbps, 500 kbps
  • Power Consumption: 3W maximum
• Operating Temperature: -25°C to +60°C (-13°F to +140°F)
• Certifications: UL Listed, CSA Certified, CE Marked

Applications:

• Industrial Automation: Enhances control and monitoring of motor starters and sensors within automated systems.
• Manufacturing Processes: Streamlines integration of discrete devices into centralized control networks.
• Material Handling Systems: Facilitates efficient control of conveyors, sorters, and other material handling equipment.
• Process Control: Integrates field devices into process control systems for improved data acquisition and control.

Why Choose the Allen-Bradley 100-DNY41R?

The Allen-Bradley 100-DNY41R Distributed Starter System DSA offers a robust solution for integrating motor starters and sensors into DeviceNet networks. Its combination of multiple input and output channels, compact design, and diagnostic features make it a valuable component in industrial automation and control applications.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
