ABB MS132-12

ABB MS132-12 | 12A Motor Protection Circuit Breaker

Overview

The ABB MS132-12 is a compact motor protection circuit breaker designed to provide reliable overload and short-circuit protection for motors up to 12A. It features an adjustable thermal trip range and an integrated magnetic trip mechanism for enhanced safety and performance.

Key Features

• Rated Current: 12A
• Adjustable Thermal Overload Setting: 8-12A
• Magnetic Trip Setting: Fixed at 13x Ie (inrush current protection)
• Short-Circuit Protection: Up to 100kA breaking capacity
• Phase Failure Sensitivity: Ensures motor protection in case of phase loss
• Compact Design: Space-saving for control panels
• Manual ON/OFF Switch: With trip indication
• Operating Temperature: -25°C to +55°C

Technical Specifications

• Model: ABB MS132-12
• Rated Operational Voltage (Ue): Up to 690V AC
• Breaking Capacity: Up to 100kA at 400V
• Trip Class: 10A
• Mounting Type: DIN rail
• Certifications: IEC 60947-2, IEC 60947-4-1, UL, CSA

Applications

• Motor Protection (Pumps, Fans, Conveyors)
• Industrial Automation
• Control Panels
• HVAC Systems

The ABB MS132-12 provides robust motor protection with adjustable settings, making it ideal for industrial and commercial applications requiring reliable motor control and safety.

Return to the ABB Contactors and Contactor Relays collection

Explore the ABB Industrial Automation Products main category

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
