ABB ACS355-03E-15A6-4 | 3ABD0000058251

ABB ACS355-03E-15A6-4 | 15 HP VFD, 480 V, 3-Phase, IP20

Global Commercial Alias: ACS355-03E-15A6-4
Product ID: 3ABD0000058251
ABB Type Designation: ACS355-03E-15A6-4
Catalog Description: Variable Frequency Drive, 15 HP, 3-phase 480 V input, IP20 enclosure

Overview

The ABB ACS355-03E-15A6-4 is a powerful variable frequency drive designed for industrial motor control applications. It provides exceptional performance in controlling motors, delivering energy-efficient and reliable solutions for various applications such as pumps, fans, and conveyors.

Key Features

• Power Rating: 15 HP (11 kW)

• Input Voltage: 380–480 V AC, 3-phase

• Output Current: 15 A

• Control Modes: Scalar (V/Hz), Sensorless Vector

• Integrated I/O: Digital and analog inputs/outputs

• Built-in EMC Filter: Yes

• User Interface: Keypad optional

• Enclosure: IP20

• Mounting: DIN rail or wall-mount

Technical Specifications

• Frequency Range: 0–500 Hz

• Overload Capacity: 150% for 60 seconds

• Operating Temperature: -10°C to +50°C

• Dimensions (H x W x D): 230 mm x 170 mm x 230 mm

• Weight: Approx. 4.2 kg

• Certifications: CE, UL, cUL, RoHS

Applications

• Industrial pumps and fans

• Conveyor systems

• General motor control in machinery and automation

• Process control and automation

Product Description

The ABB ACS355-03E-15A6-4 VFD is a versatile motor controller, ideal for high-performance industrial applications. Offering both energy efficiency and ease of installation, it is designed to control motors with reliability and precision in demanding environments.

Why Choose ABB ACS355-03E-15A6-4?

• Energy-efficient with superior motor control

• Compact and easy to install

• Designed for harsh industrial environments

• Reliable operation in controlling pumps, fans, and conveyors

Order Now

Available for worldwide delivery.

Return to the ABB ACS355 Machinery Drives collection.

Explore the ABB Industrial Drives main category.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
