Overview

The Allen-Bradley 1762-OW16 is a 16-point relay output module designed for MicroLogix 1200 controllers. It supports both AC and DC voltage outputs, making it a versatile and reliable solution for industrial automation applications.

With its high switching capacity and durable electromechanical relays, this module ensures long-lasting performance in process control, machine automation, and industrial monitoring systems.

Key Features

• 16 Relay Outputs – Provides flexible output control for various devices
• Wide Voltage Range Compatibility –
  • 5-265V AC
  • 5-125V DC
• Electromechanical Relay Switching – Ideal for controlling loads with high voltage/current variations
• Compact DIN Rail and Panel Mount Design – Saves space in control panel installations
• Optical Isolation Between Outputs and Logic Circuits – Enhances reliability and protection
• LED Status Indicators – Provides quick diagnostics and troubleshooting

Technical Specifications

• Model: 1762-OW16
• Series: MicroLogix 1200
• Number of Outputs: 16
• Output Type: Relay (Electromechanical)
• Voltage Range:
  • AC: 5-265V
  • DC: 5-125V
• Current Ratings:
  • AC: 2.5A per point (Max), 8A per module
  • DC: 2.5A per point (Max), 8A per module
• Response Time: 10ms (On/Off)
• Isolation Voltage: 1500V AC (Optically isolated)
• Power Consumption: 0.8W
• Operating Temperature: 0°C to 55°C (32°F to 131°F)
• Mounting: DIN Rail or Panel Mount

Applications

• Industrial Automation Systems – Controls motor starters, solenoids, and other field devices
• Factory and Machine Control – Reliable switching of AC/DC loads in automation processes
• MicroLogix 1200 Expansion – Adds relay outputs to existing MicroLogix control systems
• Building Automation – Ideal for lighting, HVAC, and process control applications

Why Choose the Allen-Bradley 1762-OW16?

• Reliable and High-Durability Relay Outputs – Handles various industrial load types
• Wide Voltage Compatibility – Supports both AC and DC outputs
• Seamless Integration with MicroLogix 1200 – Expands system functionality
• Compact and Efficient Design – Space-saving module for industrial control panels
