Allen-Bradley 1756-PA72 | ControlLogix 85-265V AC Power Supply, 5V 10A

Allen-Bradley 1756-PA72 | ControlLogix 85-265V AC Power Supply, Rack Mount

Overview

The Allen-Bradley 1756-PA72 is a rack-mounted AC power supply designed for ControlLogix systems, delivering stable and efficient power to chassis modules. Operating on a wide input voltage range of 85-265V AC, it provides 5V DC at 10A, ensuring reliable performance for industrial automation applications.

This power supply mounts directly on the left side of a ControlLogix chassis, plugging into the backplane to power all installed modules. It is compatible with Series A and B ControlLogix chassis.

Key Features

• Wide Input Voltage Range: 85-265V AC
• Nominal Input Voltage: 120V/220V AC
• High Output Power: 5V DC @ 10A
• Supports Multiple Voltage Levels:
  • 1.2V @ 1.5A
  • 3.3V @ 4A
  • 5.1V @ 10A
  • 24V @ 2.8A
• Mounts Directly to the Left Side of the Chassis – No additional wiring required
• Backplane Connection for Power Distribution – Seamlessly powers all installed modules
• Compatible with ControlLogix Chassis Series A and B
• Industrial-Grade Durability – Designed for continuous operation in demanding environments

Technical Specifications

• Model: 1756-PA72
• Series: ControlLogix
• Input Voltage Range: 85-265V AC
• Nominal Voltage: 120V / 220V AC
• Input Frequency: 47-63 Hz
• Maximum Input Power: 100VA / 100W
• Output Power: 75W @ 0-60°C
• Power Dissipation: 25W @ 0-60°C
• Hold-Up Time (VAC @ 50/60 Hz):
  • 5 cycles @ 85V AC
  • 6 cycles @ 120V AC
  • 6 cycles @ 200V AC
  • 6 cycles @ 240V AC
• Maximum Inrush Current: 20A
• Isolation Voltage: 250V Continuous
• Mounting Location: Left side of the 1756 ControlLogix chassis
• Weight: 1.12 kg (2.10 lbs)
• Operating Temperature: 0°C to 60°C (32°F to 140°F)

Applications

• ControlLogix PLC Systems – Provides reliable and stable power to chassis modules
• Factory and Process Automation – Ensures continuous and uninterrupted operation
• Industrial Power Distribution – Powers ControlLogix I/O and communication modules
• Machine Control and Robotics – Supports high-performance automation systems

Why Choose the Allen-Bradley 1756-PA72?

• Reliable and Efficient Power Supply – Ensures consistent power distribution
• Seamless ControlLogix Integration – Mounts directly to Series A and B chassis
• Wide Voltage Compatibility – Supports 85-265V AC input
• Durable Industrial Design – Optimized for harsh environments

Order Now

Fast shipping and worldwide delivery available.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
